To upload individual objects to the BIMcloud, first place them into a folder, then upload the folder. Once libraries are uploaded, individual users can add these BIMcloud Libraries to projects, either solo or Teamwork.
Detailed management: Modify hosted data on BIMcloud Server. Simplified management: Server administrator. To upload a library to a different BIMcloud Server (other than the default), click the pop-up. Check Host Server: The default host server is shown, where the library will be uploaded. You cannot upload individual gsm files you can only upload. Browse for the library you wish to upload. Go to File > Libraries and Objects > Manage BIMcloud Libraries.ģ. If you do not have permission to upload to a particular folder, you are prompted to choose the default folder.ġ. Simplified management: Project or Server administrator. The feedback tells you the result of the update. It must be a newer library of the same name.ĥ. Browse for the library with which to replace the selected library. Use this command to update a selected library (already uploaded to the BIMcloud) with a newer library of the same name.ģ. If a library of the same name already exists within a folder on the BIMcloud, you cannot upload it: any given library can exist only once in a given BIMcloud location.īIMcloud Libraries are listed with upload date and the address of the host server.
(Click the Manage Folders link from the New Folder drop-down button to access the Projects page of the BIMcloud Manager.) The folder is created immediately you can delete or otherwise manage it only through the browser-based BIMcloud Manager.
Detailed Management: Modify details and Modify folder content for the destination folder. Simplified Management: Project or Server Administrator. In Tree view, use Create Folder to create a new one on the Projects root. To show the libraries only, uncheck Show All Items. The tree view displays not only libraries, but also their position within the hierarchy of BIMcloud Manager (Projects root).īoth projects and libraries are listed by default. Use either the Tree view, or switch to a Flat list using the icons at top right.
From Library Manager, click the Manage BIMcloud Libraries iconĪt the top of the dialog box, use the pop-ups to choose a BIMcloud and to log in.Ĭlick the green Refresh button as needed to refresh the library list and user pop-up information shown in this dialog box. use File > Libraries and Objects > Manage BIMcloud Libraries. To open this dialog box, do one of the following:
Note: In a Teamwork project, you must be a Project or Server Administrator to use this dialog box. To use a BIMcloud Library in a project (either solo or Teamwork), that library must first be uploaded to the BIMcloud, using this dialog box. Use the Manage BIMcloud Libraries dialog box to view, upload and otherwise manage the libraries on any BIMcloud.
